Miscellaneous / Other / VAIOCS 1G
-
Inventory number 231619
-
Machine type VAIOCS 1G
-
Producer EMO
-
YOM 2009
| Max. dimensions of workpiece | 530x320x200 mm |
| Max. weight of workpiece | 70 kg |
| Machine weight | 3000 kg |
| Machine dimensions l x w x h | 2800x1750x2400 mm |
Subject to change of technical parameters.
Description
The machine is in excelent condition. Possible to test under power.
Cleaning process - dip-degreasing with solvent alternatively with ultrasonic.
- Immersion
- Intermediate drying
- Vapour degreasing
- Vacuum drying
All steps alternatively with basket motion
Batch dimensions 530 x 320 x 200 mm
Performance 8-10 batches/h (normal programme)
Batch weight max. 70 kg
Solvent hydrocarbon, modified alcohol
Content Solvent approx. 450 litres
Electrical output:
Heat output 33 kW
Motor output 13 kW
Cooling output approx. 15 kW
power requirement approx. 51 kW / 90 A
Operating voltage 400 V / 50 Hz / 3/N/PE
Pressurised air approx. 6 bar
Amount of exhaust airapprox. 63 m3/h
